All in one heat pump series C
R134A refrigerant, environmentally friendly
External condenser coil, more safe & reliable
High pressure protection
·R134A refrigerant, environmental friendly.
·Higher water temperature output up to 75ºC.
·External condenser coil, more safe & reliable.
·Adopt enamel inner tank.
·High pressure protection.
·Defrost automatically.
·With sterilization function.
·MODBUS communication.
·Full automatically operation.
·With auxiliary electric heater.
·Top air in/out with duct, free of cool air.
| Model | YT-200/250/300TB1 |
| Heating Capacity (kW) | 2.5 |
| Power Input (kW) | 0.6 |
| COP | 4.16 |
| Max Power Input (kW) | 2.4 |
| Rated Current (A) | 2.7 |
| Max Current (A) | 12.2 |
| Power Supply | 220V/1/50Hz |
| Backup Electric Heater (W) | 2000 |
| Refrigerant | R134a |
| Net Dimension (mm) | φ620*1638mm φ620*1868mm φ620*2038mm |
| Package Dimension (mm) | 700*700*1830mm 700*700*2060mm 700*700*2230mm |
| Net Weight (kg) | 88/95/102 |
| Gross Weight (kg) | 106/113/120 |
| Noise (dB) | 48 |
| Water tank volume (L)/(Gal) | 200/55 250/66 300/80 |
| Working temperature range (℃) | -7~43 |
| Loading quantity （20ft container） | 24 |
| Loading quantity （40ft container） | 51 |
